PLATFORM HIGHLIGHTS
Provides cable TV technicians with a next-generation plant maintenance tool with Sweep & Spectrum Analysis
Easy-to-use WinCE system minimizes training and maximizes testing accuracy and consistency
Compatible with existing CaLan® sweep installations - works side by side with legacy deployments
Open architecture design provides suppport for a variety of devices and future applications
Interfaces to the web-based realGATE™ Test Management system, providing a full array of management tools for tracking assets, analyzing test data and implementing workforce management
Simplifies Proof-of-Performance testing
Use WiFi option, Ethernet or cable modem to access back office systems and manage test results
Advanced Gated measurements allow characterization & troubleshooting closer to the source
KEY FEATURES
New Fast Spectrum with 0.3 uSec sample rate
Now with Equalizer Stress, Frequency Response and Group Delay measurements in Digital & Cable Mode
i-QAM option identifies impairments in a QAM signal
Gated CCN, CSO, CTB & HUM tests on active channels
DOCSIS 3.0 Cable Modem with up to 8 DS and 4 US bonded channels
High resolution true non-interfering 5 to 1000 MHz downstream sweep system with manual & automatic Gain & Slope offsets
Future proof flexible and upgradeable DSP software defined receiver technology
Fast 5 to 200 MHz upstream sweep, plus ingress detection and display
WiFi 802.11g Wireless USB adapter option
Fast 1 GHz Spectrum Analyzer with 1,000 MHz Span and 1 MHz to 30 kHz RBW
6.4” full VGA, color touch screen (daylight visible)
BPI+ and PacketCable™ digital certificates installed
Weather and shock resistant
Net-Tools: ping, trace, throughput and IP details via WiFi, Ethernet and Cable Modem
User programmable automated 24 hour testing
Additional applications for live search, Telnet, SNMP, FTP, Remote Desktop plus options for WiFi, Signature Capture and more
